數控焊接設備在日常使用中難免會出現一些故障，引起問題的原因有很多，從平時的經驗總結看來，一般有四點，為了避免其出現故障，我們可以做好日常的保養工作，延長山東數控焊接設備的使用壽命。

It is inevitable that some faults will occur in the daily use of the CNC welding equipment. There are many reasons for the problems. From the usual experience summary, there are generally four points. In order to avoid the faults, we can do a good job in the daily maintenance and extend the service life of the Shandong CNC welding equipment.

故障原因：

Fault cause:

1、環境保護不當，如果空氣中濕度過大及有靜電作用，同時焊接現場粉塵較大，就很造成控制柜內積塵，產生誤動作，引發故障。

1. Improper environmental protection. If the humidity in the air is too high and there is electrostatic effect, and the welding site dust is large, it is likely to cause dust accumulation in the control cabinet, resulting in misoperation and causing failure.

2、操作不當造成的人為故障，如果操行不當，會造成數控焊接設備隨動不見變形，比如數控焊接設備焊槍損壞、裝卸工件不當，所以操作人員在使用時要小心。

2. Human failure caused by improper operation will cause the following deformation of the NC welding equipment, such as damage to the welding gun of the NC welding equipment and improper loading and unloading of the workpiece. Therefore, operators should be careful when using.

3、插接板接口發生腐蝕性氧化，接觸不當，引起無法開機或設備工作不穩定。

3. Corrosive oxidation and improper contact of the connector board interface lead to failure to start the machine or unstable operation of the equipment.

4、外部的設備設計制造不精致造成故障，升降平臺開關和線纜問題、示教器顯示部分元器件質量問題。

4. The external equipment is not designed and manufactured accurately, resulting in faults, lifting platform switch and cable problems, and the quality of some components of the teaching pendant display.

如果因以上問題造成了數控焊接設備的故障，那就是平時的保養工作沒有做好了，接下來小編http://m.opedost.com為大家簡單介紹幾個關于數控焊接設備日常保養的問題，希望能幫助到大家。

If the CNC welding equipment fails due to the above problems, it is that the usual maintenance work is not done well http://m.opedost.com I would like to briefly introduce a few questions about the daily maintenance of CNC welding equipment for you, hoping to help you.

1.每日清理設備主驅動輪托輪、電ji導桿、電ji上的飛濺物、臟物及灰塵。

1. Clean the splash, dirt and dust on the main drive wheel carrier, electric ji guide rod and electric ji of the equipment every day.

2.定期檢查各運動部件的潤滑，尤其是變徑滑板，電ji導桿和變徑絲杠，一定要每天都潤滑。

2. Regularly check the lubrication of all moving parts, especially the variable diameter slide plate, electric ji guide rod and variable diameter lead screw, which must be lubricated every day.

3.還要檢查電ji工作面的磨損情況，如發現電ji溝槽過深或粘附嚴重，應立即修理或更換。

3. Also check the wear condition of the electric ji working surface. If the electric ji groove is found to be too deep or adhesion is serious, repair or replace it immediately.

4.檢查中間軸兩端法蘭、變徑系統軸承座、限位輪緊固螺栓的緊固情況，如發現松動，立即緊固。等等。

4. Check the fastening of the flanges at both ends of the intermediate shaft, the bearing seat of the reducing system, and the fastening bolts of the limiting wheel. If any looseness is found, tighten it immediately. wait.

數控焊接設備如果不做好平時的日常檢查保養工作很容易出現問題的，所以以上提到的幾點保養措施一定要做好，另外大家如果遇到了故障，記得要及時檢查維修。

If the NC welding equipment is not properly checked and maintained, it is easy to have problems, so the above mentioned maintenance measures must be well done. In addition, if you encounter faults, please remember to check and repair in time.
