自動焊接設備是一種為焊接提供一定電源特性的設備，廣泛應用于現代工業生產。自動焊機的裝置和操作一定符合技術規范和規范，這直接關系到焊接操作的作用。那么今天小編就帶大家一起了解一下山東自動焊接設備的運轉及相關操作。

Automatic welding equipment is a kind of equipment that provides certain power characteristics for welding and is widely used in modern industrial production. The device and operation of automatic welding machine must conform to the technical specifications and specifications, which is directly related to the role of welding operation. So today, Xiaobian will take you to understand the operation and related operations of Shandong automatic welding equipment.

1.按要求裝置好電加熱式CO2氣體減壓器

1. Install the electrically heated CO2 gas pressure reducer as required

2.運用前有必要先預熱5-10分鐘;

2. It is necessary to preheat for 5-10 minutes before use;

3.緩緩將氣瓶上的閥門打開(速度約5度/秒)，這時可觀察到壓力表的指針慢慢抬起，然后停在適宜的刻度上。

3. Slowly open the valve on the cylinder (at a speed of about 5 degrees/second), and then observe that the pointer of the pressure gauge slowly rises, and then stops on the appropriate scale.

4.閉合設備電氣箱空氣開關對設備上電，檢查電氣箱和機身是否漏電(發現漏電須掃除后進行下一步操作)。

4. Close the air switch of the electrical box of the equipment to power on the equipment, and check whether the electrical box and the machine body have leakage (if any leakage is found, clean it up and carry out the next operation).

6.檢查減速箱是否加注潤滑油，發現異常須按本減速機保護規范處理。

6. Check whether the gearbox is filled with lubricating oil. If any abnormality is found, it shall be handled according to the reducer protection specification.

8.在操作面板上挑選正確作業狀態：“調試”檔位合適本機手動操控作業;“自動”檔位合適程序化自動焊接作業。

8. Select the correct operation status on the operation panel: the "commissioning" gear is suitable for manual operation of the machine; "Automatic" gear is suitable for programmed automatic welding operation.

9.調整好適當參數(作業臺回轉速度)和正確轉向，啟動設備進行正常操作和作業。

9. Adjust the appropriate parameters (table rotation speed) and correct steering, and start the equipment for normal operation and operation.

10.能夠在焊機的操控面板上進行功用挑選和部分參數設定。

10. Be able to select functions and set some parameters on the control panel of the welding machine.

11.焊機的操控面板所對應的功用有指示燈顯示，在運用過程中對應的指示燈被點亮即可進行對應的操作。(特別留意當焊機過熱時，機內溫度指示燈會被點亮，此刻留意操控好焊機的運用時間或暫停運用該設備)

11. The function corresponding to the control panel of the welding machine has indicator light display, and the corresponding operation can be carried out when the corresponding indicator light is lit during operation. (Pay special attention to that when the welding machine overheats, the temperature indicator in the machine will be lit. At this moment, pay attention to the operation time of the welding machine or suspend the use of the equipment)

以上就是對自動焊接設備運轉以及未來發展方向的詳細介紹，希望通過介紹，大家對自動焊接有了更加深入的了解，想要了解更多關于自動焊接發展前景以及創新技術，請點擊官網http://m.opedost.com！

The above is a detailed introduction to the operation of automatic welding equipment and its future development direction. I hope that through the introduction, you can have a deeper understanding of automatic welding. If you want to know more about the development prospect and innovative technology of automatic welding, please click the official website http://m.opedost.com ！
